AGCO RT120 Tractor 150 hp Features, Performance, and Specifications
AGCO RT120 Tractor 150 Hp
The AGCO RT120 is a 150 horsepower tractor used on farms around the world. This model is valued for its strength, dependable design, and wide range of features suitable for many tasks.
| Topic | Details |
|---|---|
| Production & Identification | 2002-2004, multiple models, RT series |
| Manufacturer / Brand | AGCO Corporation |
| Model Number / Series | RT120, RT Series |
| Factory Of Manufacture | Beauvais, France |
| Years Produced | 2002–2004 |
| Original List Price (Launch) | Around $85,000 USD (estimate, 2004) |
| Serial-Number Location | Inside cab, front of right frame |
Production & Identification
AGCO RT120 tractors were built mainly between 2002 and 2004. This tractor is part of the RT series, which replaced earlier lines from AGCO.
The RT120 uses a 6.6L diesel engine that lets it reach about 150 horsepower at the engine and about 120 horsepower at the Power Take-Off (PTO). These tractors can be found in both two-wheel and four-wheel drive versions.
The serial number helps you tell the exact production year and version. AGCO RT120 units have design features like a cab with standard air conditioning and electronic controls, making them easy to identify compared to older models.
Manufacturer / Brand
The RT120 tractor is made by AGCO Corporation. AGCO is a large American company known for producing farm equipment.
The company’s roots go back to the 1990s when it gathered well-known names like Massey Ferguson and Challenger under one brand. Their dealers can help you with parts, service, and information specific to RT120 tractors.
Model Number / Series
This tractor is known as the RT120. It is part of the RT series lineup.
The RT series includes various models grouped by horsepower, and RT120 sits in the middle as a strong mid-sized tractor. Your RT120 comes with a model badge, usually on the hood and inside the cab.
Factory Of Manufacture
The main factory for the AGCO RT120 is in Beauvais, France. This factory is well-respected for its large-scale, high-quality production of tractors for the European and North American markets.
Beauvais is known for modern robotics and strict testing. Your RT120 left this location finished to high standards.
Years Produced
The AGCO RT120 was produced from 2002 until 2004. This three-year run included several updates to controls and small changes as feedback from early users was reviewed.
Production of the RT120 stopped as AGCO continued improving its tractor line-up. If you want a used RT120, focus on those made in the later years as they often include extra features or minor upgrades.
Original List Price (Launch Year)
The RT120 was priced at about $85,000 USD when first launched. Prices varied based on trim, options, and local taxes.
At launch, this price put the RT120 right in the middle for high-horsepower row-crop tractors. Today, you might see used models selling between $26,500 and $52,950 depending on condition and features.
Serial-Number Location
You can find the serial number for the AGCO RT120 in two main places. The most common location is inside the cab, often on a plate by the operator’s seat or the instrument panel.
Another place is the front of the right-hand frame, stamped on a metal tag. Writing down your serial number helps when ordering parts or checking for recalls.
| Subsection | Key Details |
|---|---|
| Production & ID | 2002–2004, RT series, two- or four-wheel drive |
| Manufacturer / Brand | AGCO, major US-headquartered farm equipment brand |
| Model Number / Series | RT120, part of RT Series lineup |
| Factory | Beauvais, France |
| Years Produced | 2002–2004 |
| List Price | ~$85,000 USD (2004), used: $26,500–$52,950 |
| Serial # Location | Inside cab & right front frame |
Engine Specifications
The AGCO RT120 tractor is equipped with a high-performing diesel engine designed to deliver a strong balance of power, efficiency, and reliability for demanding fieldwork. This section details the engine’s technical features, from make and displacement to cooling system.
Engine Make & Model
The AGCO RT120 uses a Cummins engine, which is known for its durability in agricultural equipment. The specific model is the Cummins 6.6L diesel, a 6-cylinder turbocharged design.
Cummins is respected for engines that handle heavy loads and long working hours without excessive wear. Serviceability is straightforward because of common Cummins parts and wide service network coverage.
Bolted-on components allow for easier maintenance or replacement, which can help minimize your downtime and repair costs.
| Specification | Detail |
|---|---|
| Engine Manufacturer | Cummins |
| Engine Model | 6.6L Diesel |
| Turbocharged | Yes |
| Number of Cylinders | 6 |
Fuel Type & Emissions Tier
The RT120 engine is powered by diesel fuel, utilizing direct injection for efficient combustion. Direct injection ensures fuel is accurately delivered to each cylinder for optimal use, improving both power output and fuel economy.
Emissions standards depend on the specific model year. Most AGCO RT120 tractors meet at least Tier 2 requirements for off-road diesel engines.
Because it is not an electronically controlled engine, it does not use complex emission control systems such as DEF or particulate filters commonly seen on newer tractors. This makes maintenance more straightforward and reduces long-term operating costs.
| Feature | Specification |
|---|---|
| Fuel Type | Diesel |
| Fuel Delivery | Direct Injection |
| Emissions Tier | Tier 2 |
| DEF Required | No |
| Electronic Control | No |
Cylinders / Displacement
You get a straight-six cylinder configuration that is widely regarded for its smooth operation and balanced power delivery. All six cylinders fire in sequence to limit vibration, making it comfortable for long operation hours.
The displacement of the engine is approximately 6.6 liters, or 402.8 cubic inches. This large displacement gives you better low-end torque, which is critical for pulling implements or heavy loads.
| Specification | Value |
|---|---|
| Cylinder Count | 6 |
| Configuration | Inline (I-6) |
| Displacement | 6.6 L / 402.8 cu in |
| Firing Order | 1-5-3-6-2-4 |
Rated Horsepower (Gross & Net)
The AGCO RT120’s Cummins engine produces a rated gross horsepower of 150 hp at 2200 RPM. Net horsepower, which reflects the power available for work after subtracting energy used by the engine’s own systems and accessories, is slightly lower but still provides excellent pulling ability for row-crop and field duties.
PTO (Power Take-Off) horsepower is measured at roughly 120 hp. This means you can expect high efficiency when powering implements such as mowers, balers, or sprayers.
| Power Output | Value |
|---|---|
| Gross Horsepower | 150 hp (@2200 RPM) |
| PTO Claimed Horsepower | 120 hp |
| PTO Tested Horsepower | 122.2 hp |
| Net Horsepower | ~140-145 hp |
Peak Torque (Nm @ Rpm)
The RT120 engine delivers substantial torque for tough jobs in the field. Peak torque increases your ability to handle heavy loads without lugging or losing momentum.
While the exact figure is not always published, a 6.6L Cummins diesel like this typically produces around 600–650 Nm (about 440–480 lb-ft) of peak torque. Peak torque is generally delivered close to 1400–1500 rpm, where most heavy pulling occurs during field operations.
This low-end torque allows you to keep moving efficiently when the tractor is subjected to load changes, such as hills or heavy implements.
| Torque Output | Value |
|---|---|
| Peak Torque (Estimated) | 600–650 Nm |
| Peak Torque (lb-ft) | 440–480 |
| RPM @ Peak Torque | 1400–1500 |
Compression Ratio
The engine uses a compression ratio of approximately 17.5:1. High compression ratios are common in diesel engines to ensure reliable ignition of the fuel-air mixture by heat generated from compression alone, rather than spark plugs.
This higher compression helps achieve better thermal efficiency, translating to improved fuel economy and stronger torque characteristics.
| Specification | Value |
|---|---|
| Compression Ratio | 17.5:1 |
Cooling System & Capacity
Efficient cooling is essential for engines operating under heavy loads for long hours. The AGCO RT120 uses a liquid-cooled system with a radiator and water pump.
This helps manage engine temperature and prevents overheating, even in hot weather or during prolonged field work. The system includes a large-capacity radiator, hoses, and a coolant reservoir.
It holds about 24 quarts (about 22.7 liters) of coolant. You should check coolant levels regularly to prevent engine overheating.
| Attribute | Specification |
|---|---|
| System Type | Liquid (Water Cooled) |
| Radiator Capacity | 24 quarts (~22.7 L) |
| Components | Radiator, hoses, pump |
| Maintenance | Regular coolant checks |
Engine Specification Summary Table
| Feature | Detail/Value |
|---|---|
| Engine Make | Cummins |
| Model | 6.6L Diesel |
| Fuel Type | Diesel (Direct Injection) |
| Emissions | Tier 2 |
| Cylinders | 6 (Inline) |
| Displacement | 6.6 L (402.8 cu in) |
| Gross Horsepower | 150 hp @ 2200 RPM |
| PTO Horsepower | 120–122.2 hp |
| Peak Torque | 600–650 Nm @ 1400–1500 RPM (Est.) |
| Compression Ratio | 17.5:1 |
| Cooling System | Liquid Cooled, 24 quarts (22.7 L) |
Power Take-Off (PTO)
The AGCO RT120 features a robust power take-off system that supports a wide range of implements. Its PTO delivers strong horsepower, offers flexible connection options, and supports multiple speeds to match different farming needs.
| Feature | Details |
|---|---|
| Claimed PTO HP | 120 hp (claimed), 122.2 hp (tested) |
| PTO Type | Independent, Rear PTO |
| PTO Speeds | 540 / 1000 RPM |
| Front PTO | Optional |
| Control | Mechanical lever or electronic (model dependent) |
Claimed PTO Horsepower
The AGCO RT120 tractor lists a claimed PTO horsepower of 120 hp. This means you can expect the power take-off shaft to deliver up to 120 horsepower to your implements, such as balers, mowers, or sprayers.
On test stands, some reports show slightly higher results, with a tested PTO horsepower around 122.2 hp. This gives you some assurance that the machine can maintain strength under actual working loads.
PTO Type (Independent / Live / Economy)
The RT120 uses an independent rear PTO system, which allows you to control the PTO separately from the tractor’s main transmission. This type offers convenient operation because you don’t need to engage or disengage the main clutch to start or stop the PTO shaft.
The PTO is typically operated by a dedicated lever or control switch. This setup means you can power your implements while the tractor is stopped or moving, giving you more control and efficiency.
The rear PTO is standard, while a front PTO is available as an option for those who use front-mounted equipment. Independent PTOs are common on modern row-crop tractors and are preferred for their ease of use.
You can also find Economy PTO options on some models, which allow operation at reduced engine speed. This can be useful for light-duty work, helping to save on fuel and reduce wear.
PTO Speeds (540 / 1 000 Rpm)
The RT120 supports multiple rear PTO speeds: 540 and 1000 rpm. This dual-speed system allows you to match the PTO shaft speed to the implement’s requirements.
Many smaller implements and traditional farm tools use the 540 rpm shaft. More modern or high-capacity equipment often uses the 1000 rpm speed for greater power transfer and efficiency.
Switching between the two speeds is usually done by adjusting the PTO shaft or selector, depending on your implement. If you choose the optional front PTO, it may have different speed settings to fit front-mounted tools.
Transmission & Drivetrain
The AGCO RT120 comes with advanced features for smooth power delivery and traction. You get reliable performance in the field and on the road thanks to multiple transmission and drive options.
Transmission Type (Syncro, Powershift, CVT, HST)
The AGCO RT120 is equipped with a Continuously Variable Transmission (CVT), known as the PowerMaxx CVT. This transmission allows you to change speed seamlessly without the need to shift between set gears.
With CVT, you can find the exact speed needed for different tasks, whether you’re planting, tilling, or transporting. CVT systems like this use advanced hydraulics and planetary gear sets to provide smooth acceleration and efficient power transfer.
Unlike manual or Synchro transmissions, you never have to worry about grinding gears or losing momentum during a shift. This setup gives you full control with less effort, making long days behind the wheel less tiring.
Some models of the RT series are available with a 24-speed partial powershift or even a 32-speed partial powershift. The PowerMaxx CVT is especially valued for use in row-crop and heavy fieldwork because of its ability to maintain constant speed under changing loads.
Number Of Gears / Ranges
If your AGCO RT120 is fitted with the PowerMaxx CVT, you don’t select gears in the traditional sense. Instead, the CVT offers infinite speed choices within a set operating range.
This means you can smoothly move from a crawl to top speed without distinct gear steps. Other available transmissions include a 24-speed or 32-speed partial powershift.
These gearboxes provide several gear ranges, letting you shift through numerous gears within fast and slow ranges. The 24-speed partial powershift allows for semi-automatic shifts under load, making it easier to match your speed to the job without stopping.
Here’s a basic comparison:
| Transmission Type | Gear Count | Shifting Method |
|---|---|---|
| PowerMaxx CVT | Infinite (within range) | Stepless |
| 24-speed partial powershift | 24 | Semi-automatic |
| 32-speed partial powershift | 32 | Semi-automatic |
Top Transport Speed
The top transport speed of the AGCO RT120 tractor can reach around 25 mph (40 km/h), depending on tire size and transmission setup. The CVT makes it possible to maintain any speed up to this limit, which is useful if you need to travel long distances between fields or along public roads.
A higher transport speed reduces the time you spend moving from one location to another, increasing your productivity during the busiest seasons. This speed is competitive for its size class and matches or exceeds many similar tractors.
You have the ability to precisely control low speeds for implement work, but you can also reach max speed quickly and comfortably for highway driving. This flexibility is an important reason why CVT tractors are preferred for both farm and transport work.
Drive (2WD / 4WD / AWD)
The AGCO RT120 is available in both 2WD and 4WD (all-wheel drive) configurations. Most users choose the 4WD version, as it offers better traction and stability—especially in soft or muddy fields, hilly terrain, or when pulling heavy implements.
With 4WD, power is delivered to both front and rear wheels. This feature helps you avoid getting stuck in wet soil and ensures smooth operation during tough field conditions.
If you plan to use your RT120 mainly for light transport or on paved surfaces, 2WD can be an option. For heavy fieldwork and all-season use, 4WD is recommended.
The 4WD system can usually be engaged or disengaged as needed. This lets you switch between modes if you want to save fuel during lighter work or on dry ground.
Differential-Lock & Final Drives
The differential lock on the AGCO RT120 helps you keep moving in slippery conditions. When engaged, it locks both wheels on the same axle together, so they turn at the same speed.
This is important if one wheel starts spinning in mud or on loose soil. Engaging the lock gives you extra traction until you get back on firm ground.
Most controls are foot or hand-operated for quick use when needed. Some RT120 models come with automatic differential locks that engage and disengage based on wheel slip.
The final drives on the AGCO RT120 use heavy-duty gears and axles. These are designed to handle the high power output without excessive maintenance or failure.
Robust final drives ensure effective transfer of engine power to the wheels, especially under heavy load and over rough terrain.
| Feature | Details |
|---|---|
| Transmission Type | PowerMaxx CVT (stepless); 24/32-speed partial powershift |
| Gears / Ranges | CVT: Infinite (within a range); Partial Powershift: 24/32 gears |
| Top Transport Speed | Up to 25 mph (40 km/h) |
| Drive Type | 2WD and 4WD available |
| Differential Lock | Manual or automatic; axle locking for improved traction |
| Final Drives | Heavy-duty outboard planetary or inboard gear final drives |
Steering & Brakes
The AGCO RT120 tractor uses a combination of advanced steering and robust braking systems to provide better control and safety. You get systems designed for easy handling in the field, along with reliable stopping power in a range of conditions.
Steering System (Hydrostatic / Power-Assisted / Mechanical)
The RT120 is equipped with a hydrostatic power steering system. This system uses hydraulic power to make turning the steering wheel much easier, especially when you are operating at lower speeds or moving heavy loads.
Hydrostatic steering allows precise control with less effort from you, which is essential for tasks like row-crop farming or tight maneuvering. You do not have to worry about old-fashioned mechanical or manual steering fatigue with this model.
Power-assisted steering also reduces wear and tear on your arms and shoulders after long hours in the cab. The system is designed to adapt to different driving conditions, maintaining steady and smooth performance on rough and uneven ground.
Hydrostatic steering makes it possible for you to turn the tractor with accuracy even while stationary or moving at low speeds. This is especially beneficial in confined spaces.
Turning Radius (With Brakes)
The turning radius of the AGCO RT120 is designed to be tight enough for you to maneuver easily in smaller fields or around obstacles. When using the brakes in combination with the steering system, you can make even sharper turns.
This is known as “brake-assisted turning.” By pressing one of the individual brake pedals, you can slow down just one of the rear wheels.
This allows the tractor to pivot more sharply around the slowed wheel, reducing the overall turning radius. This feature is helpful when you need to line up precisely at the end of a row or navigate around tight corners.
While direct specifications for the turning radius vary based on tire size and wheelbase, the addition of brake-assisted turning gives you greater flexibility during fieldwork. This precise handling is a major advantage when working in layouts with lots of obstacles or narrow headland spaces.
Service Brakes (Wet Disc, Dry Drum, Etc.)
The AGCO RT120 comes standard with hydraulic wet disc brakes. Wet disc brakes are sealed in oil, which keeps them cool and clean.
This reduces brake wear and gives you more consistent braking performance, even when operating under heavy loads or on slopes. Hydraulic actuation means that braking power is applied evenly to all wheels, which improves your control and safety.
Wet disc brakes need less frequent maintenance than dry drum brakes, which can be affected by dust and dirt buildup. These brakes are especially useful during repeated stops or when you are descending hills with heavy implements.
The sealed system also protects against moisture and mud that can compromise other types of brakes. This reliability is important if you regularly work in damp or uneven fields where traction can change quickly.
Parking Brake Type
Your AGCO RT120 uses an independent parking brake system, typically engaged by a hand lever within easy reach inside the cab. This system is designed to keep the tractor securely in place when parked, even on inclines.
The mechanism often connects directly to the rear wheels through additional wet disc assemblies or an integrated locking system. When set, it locks the tractor’s movement completely, giving you peace of mind when leaving the machine unattended.
The independent design also means you can set the parking brake without relying on the service brakes, ensuring there is no hydraulic pressure loss over time. Regular inspection of the parking brake linkage is important for reliable operation, especially if the tractor is parked on uneven ground or near machinery.
Table: AGCO RT120 Steering & Brakes Overview
| Feature | System Type | Key Advantages | Maintenance/Notes |
|---|---|---|---|
| Steering System | Hydrostatic Power Steering | Effortless control, precision, reduced fatigue | Check fluid levels, inspect hoses |
| Turning Radius (With Brakes) | Brake-Assisted Turning | Sharp turns, improved maneuverability | Dependent on brake and tire wear |
| Service Brakes | Hydraulic Wet Disc Brakes | Consistent braking, low wear, sealed from dirt | Monitor fluid, periodic inspection |
| Parking Brake | Independent System (Hand Lever/Lock) | Secure hold on slopes, simple operation | Inspect linkage, test engagement |
Cab & Operator Station
AGCO RT120 tractors place a strong emphasis on the comfort, safety, and control of the operator. Features in the cab are designed to improve your working conditions during long hours in the field.
| Feature | Description | Benefit |
|---|---|---|
| ROPS / Cab Option | Enclosed cab or open ROPS | Safety, Operator Preference |
| Climate Control | Air conditioning, heater, cab air filter | All-weather comfort, Clean air |
| Seat & Suspension | Adjustable seat, suspension system, ergonomic controls | Reduced fatigue, Comfort |
| Noise Level | Approx. 78-83 dB(A) measured at operator’s position | Less stress, Easier communication |
ROPS / Cab Option
You can choose between an open ROPS (Roll-Over Protective Structure) or a fully enclosed cab on the AGCO RT120. The cab is built with strong materials for safety in case of rollover.
An enclosed cab gives more protection against weather, dust, and noise. If you choose the ROPS configuration, you get an open-air experience.
This setup offers more visibility and airflow but less protection from rain or extreme temperatures. Both options come standard with safety features such as seat belts and easy exit points.
The cab version is usually preferred for longer work periods and harsh weather, providing a more comfortable environment throughout your day.
Climate Control (A/C, Heater, Filter)
Inside the enclosed cab, you will find a complete climate control system. The air conditioning helps keep you cool in hot weather, while a strong heater provides warmth in colder months.
The system uses a cab air filter to reduce dust, pollen, and other particles from getting inside. Air vents are placed for even airflow, so you get comfort no matter where you sit in the cab.
You can adjust the temperature to your liking with user-friendly controls. Even in areas with extreme weather swings, this climate control system helps you stay comfortable so you can focus on your work.
The cab filter should be checked and replaced as needed for the best air quality. Proper maintenance keeps the inside of your tractor clean and comfortable, improving your health and work results.
Seat & Suspension
The operator seat on the AGCO RT120 is built for comfort and support. It includes an adjustable suspension system to reduce bumps and jolts when driving over rough fields.
You can move the seat forward, backward, up, or down to match your size and preferred driving position. Armrests and lumbar support are available to reduce fatigue on long days.
Controls for the tractor are within easy reach, so you can make quick adjustments without straining. The steering column often tilts and telescopes, letting you set it for your comfort.
Noise Level (dB A @ Operator Ear)
Noise levels in the AGCO RT120 cab usually range from 78 to 83 decibels at the operator’s ear, depending on engine speed and load. The enclosed cab includes insulation and tight seals that reduce noise from the engine and field equipment.
Lower noise makes it easier for you to communicate with others by radio or in person. Hearing protection may still be recommended for all-day use, especially at higher engine speeds.
The ROPS model is generally louder because it lacks insulation. Longer exposure to high noise may cause fatigue, so choosing the cab version can help ensure you work in a quieter space.
Hydraulics
The AGCO RT120 uses a modern hydraulic system designed for both efficient power and precise control. Key specs like system type, flow rates, pressure, and valve setup all play an important role in how you use implements and attachments.
System Type (Open-Center / Closed-Center / PFC)
This tractor features a closed center, pressure flow compensating (PFC) hydraulic system. In a closed center setup, hydraulic fluid does not flow constantly; instead, it is pressurized and only moves as needed.
The PFC aspect means the pump responds to demand, maintaining pressure but saving on energy when the full flow isn’t needed. This setup offers you quicker and more efficient response for hydraulic implements.
It reduces wasted energy, leading to less heat buildup and lower fuel consumption. Closed center PFC systems are also quieter and last longer compared to older open center designs.
Implement Pump Flow (L Min⁻¹)
For the RT120, the primary implement pump delivers strong flow rates to your attachments. With a maximum implement pump flow typically around 98-110 liters per minute, you have more than enough hydraulic power for most row-crop and loader work.
Higher flow rates ensure that cylinders extend and retract quickly under load, so tasks are finished faster. This flow rate also allows you to run multiple hydraulic functions at the same time, useful if you need to raise an implement while adjusting another.
For heavy implements—such as big planters or front loaders—the high flow prevents slowdowns and keeps performance predictable. Your attachments respond promptly to every control input.
Steering Pump Flow (If Separate)
The steering system on the RT120 tractor is separate from the main hydraulic pump, using its own dedicated hydrostatic pump. This design ensures consistent steering response, even if other hydraulic functions are demanding high flow.
A separate hydrostatic power steering pump means steering remains easy and predictable regardless of what the implement circuit is doing. In fieldwork or transport, your steering wheel effort stays light, so fatigue is reduced, and safety is improved.
Even at slow engine speeds or heavy hydraulic load, you never lose effective steering power.
Total Combined Flow
By combining the implement pump and steering pump, total hydraulic flow available is significant. On the AGCO RT120, you may see a total combined flow of up to 120 liters per minute (implement plus steering).
Having a high total flow is important when running many hydraulic functions together. For example, when pulling a complicated planter with several hydraulic motors and also using the loader or lift, you don’t lose performance in any area.
| Feature | Specification |
|---|---|
| System Type | Closed Center, Pressure Flow Compensating (PFC) |
| Implement Pump Flow | 98 – 110 liters/minute |
| Steering Pump Flow | Hydrostatic (separate), approx. 20 liters/minute |
| Total Combined Flow | Up to 120 liters/minute |
| System Pressure | 200 bar (2,900 psi) |
| Remote Valves | Up to 4, double-acting with ISO couplers |
System Pressure (Bar / Psi)
The RT120’s hydraulic system is built to handle demanding jobs. Maximum system pressure is 2,900 psi (200 bar), which allows the tractor to lift heavy implements, run large cylinders, or operate hydraulically-powered motors without trouble.
This high pressure gives you more force when using hydraulic equipment. The system is designed with built-in relief valves to keep pressure within safe limits and protect both the pump and your attachments.
Remote Valves (Number & Type)
The RT120 can be fitted with up to four rear remote valves. Each remote is double-acting and uses standard ISO-style couplers so they work with most farm attachments.
These valves control functions like raising/lowering implement cylinders or adjusting hydraulic motors. More available remotes mean you can connect several implements at the same time without switching hoses.
The double-acting design means you can supply pressure to both extend and retract functions on your implement, giving you full control for operations like loader work, adjusters, or splitters. Remotes are usually operated by easy-to-reach levers or fingertip controls in the cab.
| Subtopic | Main Feature | Benefit to You |
|---|---|---|
| System Type | Closed Center, PFC System | Efficiency and fast hydraulic response |
| Implement Pump Flow | 98-110 L/min | Faster implement movement |
| Steering Pump Flow | Separate hydrostatic pump | Steering stays reliable under heavy load |
| Total Combined Flow | Up to 120 L/min | Multiple hydraulic functions at once |
| System Pressure | 2,900 psi (200 bar) | Handles large implements with ease |
| Remote Valves | Up to 4, double-acting, ISO couplers | Connect/control several attachments easily |
Three-Point Hitch (3PH)
The AGCO RT120 tractor is equipped with a robust three-point hitch system. It provides versatile implement handling, strong lifting capacity, and precise control for a range of field tasks.
| Feature | Specification/Detail |
|---|---|
| Hitch Category | Category 3 |
| Lift Capacity @ Ball Ends | ~8,000–9,000 lbs (varies by specific configuration) |
| Draft / Position Control | Electronic, with adjustable position and draft |
| Top-Link Sensing | Yes (supports draft control functions) |
Hitch Category (1 / 1N / 2 / 3)
The AGCO RT120 uses a Category 3 three-point hitch at the rear. This hitch type works with larger implements designed for mid- to high-horsepower tractors.
You can attach large plows, heavy cultivators, and broad tillage equipment. Category 3 pins are 1-1/4 inches (32 mm) in diameter, and the link spacing is wider than Category 2.
This means you can move heavier loads and connect to commercial-grade equipment used in row cropping or hay production. Unlike smaller tractors, a Category 3 hitch allows you to use attachments with higher power requirements.
Lift Capacity @ Ball Ends
Lift capacity at the ball ends for the AGCO RT120 falls around 8,000 to 9,000 pounds. This rating measures the strongest point of lift, where the implement attaches to the hitch arms.
You can safely handle most large rear-mounted implements such as heavy mowers, multi-row planters, or large fertilizer spreaders. If you use drawn implements, the tractor’s drawbar rating supports pulling wide equipment in demanding conditions.
The combination of strong rear lift and pull force lets you perform deep tillage or lift large pieces of equipment without worry about hydraulic strain. The higher lift capacity means you are less restricted by the weight of compatible implements.
Draft / Position Control
The RT120 gives you electronic draft and position control for the rear hitch. Position control lets you set the specific height of the attachment, so you can maintain even working depth across the field.
Draft control, supported by sensing systems on the hitch, automatically adjusts the hitch height in response to changing soil resistance. This keeps implements at a constant depth, improving traction and reducing engine load.
You can fine-tune both functions with in-cab controls. These systems work together to help you get smooth, efficient results and prevent damage to your tractor hitch or mounted tools.
Top-Link Sensing (Yes/No)
The AGCO RT120 comes equipped with top-link sensing as standard, allowing real-time draft control. With a sensor in the top link, the tractor can accurately detect changes in load and soil conditions.
This information lets the electronic control system make instant adjustments. With top-link sensing, the draft system reacts faster to rises or dips in ground resistance.
This keeps the implement level and lowers the chances of wheel slip or uneven depth, especially in difficult ground. You do not have to keep making manual corrections.
Top-link sensing supports efficient fieldwork, helps extend the life of rear implements, and reduces strain on your tractor frame and lift arms.
Axles & Load Limits
You need to understand axle capacities, load restrictions, and drive design to make sure the AGCO RT120 tractor works safely and effectively in the field. Knowing these details helps prevent equipment damage and supports long-term reliability.
Maximum Front-Axle Load (Kg)
The front axle needs to handle much of the tractor’s weight, especially when lifting heavy implements. For the AGCO RT120, the maximum front-axle load is approximately 3000 kg.
This means you should not exceed this weight on the front axle to avoid stress that can cause wear or failure. Attaching front weights or heavy loaders adds extra force to this section of the tractor.
Keep in mind that tire inflation should also be monitored and kept at the recommended pressure (typically around 160 kPa) to support this load. If you frequently use front-mounted equipment, check axle and tire condition often.
Overloading the front axle can result in steering problems and increased maintenance costs.
Maximum Rear-Axle Load (Kg)
The rear axle on the RT120 supports the majority of field implements and the bulk of the tractor’s power transmission. Its maximum load is generally rated higher than the front.
The rear axle load limit on the AGCO RT120 is about 5000 kg. This higher limit allows you to use heavy three-point hitch implements, large planters, or significant towed loads without over-stressing the rear components.
Proper ballasting and weight distribution remain important to keep the rear wheels grounded and maintain stable traction. Monitor axle hubs and rear tires for signs of excess stress, like abnormal wear or overheating.
Exceeding the rear axle load can cause premature failures or even axle breakage.
Final-Drive Type
The AGCO RT120 features a planetary final-drive system. This design uses a combination of gears to distribute the engine’s power efficiently to the wheels.
Planetary drives are known for being strong, dependable, and able to handle high torque from the 6-cylinder Cummins engine. You benefit from improved durability with this setup.
The planetary final drive helps prevent axle twisting and reduces component strain, especially when operating at the tractor’s higher power output and load limits. This setup is well suited for demanding fieldwork, such as heavy tillage or pulling large trailers.
Axle & Load Summary Table
| Feature | Maximum Value | Notes |
|---|---|---|
| Maximum Front-Axle Load | ~3000 kg | Avoid exceeding, maintain proper tire PSI |
| Maximum Rear-Axle Load | ~5000 kg | For heavy implements & towed loads |
| Final-Drive Type | Planetary | Handles high torque, offers strong design |
| Recommended Tire Pressure (Front) | ~160 kPa | Supports axle capacity |
Tires & Track Options
Tire and track options on the AGCO RT120 play an essential role in how your tractor performs in different field and work conditions. The right choice can improve your traction, reduce soil compaction, and even lower your fuel costs.
Standard Front Tire Size (Ag / Turf / Industrial)
The AGCO RT120 usually comes with standard front agricultural (Ag) tires sized around 14.9R28. These provide strong grip for fieldwork and paddock use.
For use on lawns or sports turf, you may opt for turf tires in sizes like 380/70R28, which are wider and designed to reduce marks and ground disturbance. Some operations need industrial tires.
These are often in the size range of 12.5/80-18. They work better for mixed-use tasks, such as loader work and road transport because they have a tougher sidewall and different tread pattern.
All three types are tubeless for easier repairs and better performance. Proper inflation is important for each type.
Ag tires may need to be set lower for field use, while industrial and turf options need higher pressures for carrying loads on hard surfaces. Be sure to check your manual for the correct PSI for the front tire type you choose.
Standard Rear Tire Size
For the rear wheels, the most common Ag tire size is 18.4R38 or 480/80R38. These tires help transfer the RT120’s horsepower to the ground, especially important for heavy field tasks like plowing or tillage.
Wider tires like 520/85R38 are available for additional floatation, which helps in softer soils. Rear turf tire sizes are typically wider, for example, 520/70R38.
These distribute weight better when working on turf and reduce ground damage. If you require versatility, industrial rear tires often come in similar sizes to the front, like 18.4-38, but feature heavier construction.
Load capacity should match your maximum expected rear ballast and implements. Improper fit or a mismatch between front and rear sizes can lead to drivetrain wear or reduced performance.
Optional Duals / Tracks / Flotation Kits
Dual wheels can be fitted on both front and rear axles for better traction and stability, especially in soft or muddy fields. They are often used for heavy tillage or where slip must be minimized.
Installation typically requires wheel spacers or hubs, which must be compatible with the RT120’s axle specs. Track conversion kits are becoming more common, especially in high compaction or wet soil zones.
Aftermarket kits allow swapping standard wheels for rubber tracks, which increase floatation and reduce rutting. Tracks are recommended for certain crops and when you need to avoid sinking.
Flotation kits may include extra-wide tires or special rims, further reducing ground pressure. You can order these kits as factory options or through aftermarket suppliers.
Matching these kits to your intended use ensures you get the maximum benefit in tricky field conditions.
Tires & Track Options Summary Table
| Feature | Ag Tire | Turf Tire | Industrial Tire | Duals | Track Kits | Flotation Kits |
|---|---|---|---|---|---|---|
| Front Standard Size | 14.9R28 | 380/70R28 | 12.5/80-18 | Available | Compatible | Available |
| Rear Standard Size | 18.4R38 | 520/70R38 | 18.4-38 | Available | Compatible | Available |
| Primary Use | Field work | Turf/lawn | Loader/Road | Mud/Soft soil | Wet/Soft areas | Wet/Soft areas |
| Soil Compaction | Medium | Low | Medium | Low | Very Low | Very Low |
| Ground Pressure | Normal | Lower | Normal | Lower | Lowest | Lowest |
| Special Equipment Needed | No | No | No | Yes | Yes | Yes |
| Can Be Retrofitted | Yes | Yes | Yes | Yes | Yes | Yes |
Dimensions & Weight
You can get the most from the AGCO RT120 by understanding its size, layout, and weights. This tractor is equipped for tough work, with dimensions that balance power, stability, and field adaptability.
| Specification | Measurement |
|---|---|
| Wheelbase | 109.5 in (278 cm) |
| Overall Length | ~201 in (varies with attachments) |
| Overall Width | 69.3 – 119.1 in (176 – 303 cm) |
| Height to ROPS / Cab | ~119 in (302 cm) |
| Ground Clearance | 14 in (35 cm) |
| Shipping Weight | 12,059 – 13,988 lbs (4WD, cab/CVT) |
| Operating Weight (Fluids) | 15,055 lbs (4WD, CVT cab) |
Wheelbase
The wheelbase of the AGCO RT120 is 109.5 inches (278 cm). This measurement is the distance between the centers of the front and rear wheels.
A longer wheelbase provides a smoother ride and more stability, especially when hauling or using heavy rear implements. With this length, you get reliable balance for fieldwork without giving up on maneuverability.
You’ll notice improved traction and steadiness, especially over rough ground. This is ideal for when you have to work with larger implements or when you need to carry heavy loads over uneven terrain.
Overall Length
The overall length of the AGCO RT120 is around 201 inches, but this can change based on the attachments and setup. For example, extra front weights, larger tires, or attachments can affect total length.
This length gives you room for maneuvering in tight turns while still fitting standard barns and equipment sheds. You can fit the RT120 into areas where larger tractors may not go, yet you have enough size for solid performance in row-crop and fieldwork.
This balance in length makes storing, transporting, and operating the tractor less challenging.
Overall Width (Minimum Tread)
When set to the narrowest tread, the AGCO RT120 measures about 69.3 inches (176 cm) at the rear wheels. This width can be adjusted up to 119.1 inches (303 cm) for different field and crop needs.
Setting a narrow tread is useful for row-crop operations, while a wider tread adds stability on hills or with heavy implements. Changing the tread width lets you use the tractor for many types of farming, from narrow row crops to wide, open fields.
If you need different widths for stability or crop spacing, you can make these adjustments fairly easily.
Height To ROPS / Cab
The AGCO RT120 stands around 119 inches (302 cm) tall at the top of the cab. The ROPS (Rollover Protective Structure) is part of the cab for operator safety.
This height is important if you have to move the tractor in and out of buildings. Make sure your doors and storage areas can handle this height to avoid problems.
The cab height allows for good operator visibility above most crops and other obstacles in the field. Even at this height, you get lots of headroom and a spacious cab area for longer jobs.
Ground Clearance
With a ground clearance of 14 inches (35 cm) at the drawbar, the RT120 can clear stubble, residue, and uneven ground. This lets you navigate fields without worrying about getting stuck on ruts or debris.
If you do a lot of row-crop or specialty crop work, this clearance keeps key parts of the tractor above the plant line. It also protects the undercarriage and important components from damage.
Extra clearance means you can use this tractor for a variety of tasks, including planting, spraying, and field mowing.
Shipping Weight
The shipping weight of the AGCO RT120 varies depending on model and equipment. For a 4WD model with a cab, the shipping weight is about 12,059 lbs (5,469 kg).
With a CVT cab, it goes up to 13,988 lbs (6,344 kg). Shipping weight does not include fuel, fluids, or extra ballast.
This is the weight when moving the tractor from the factory. Knowing the shipping weight is important for transporting the tractor on a trailer or truck.
It helps you make sure you have the right equipment and stay within legal limits during road transport.
Operating Weight (With Fluids)
When fully fueled, oiled, and ready for use, the AGCO RT120 weighs up to 15,055 lbs (6,828 kg) with the CVT cab model. This is called the “operating weight,” and it includes standard fluids.
This weight is what you will usually be working with in daily use. Heavier operating weight gives better traction in the field, which helps when pulling large implements or hauling full loads.
Extra ballast or weights can be added for very heavy jobs. You should be careful not to overload beyond safe limits, to avoid wear or mechanical issues.
Fuel & Fluids
The AGCO RT120 tractor uses specific types and amounts of fluids to ensure reliable performance. Knowing these details helps you keep the machine running efficiently and reduces the risk of mechanical problems.
Fuel-Tank Capacity
The AGCO RT120 tractor comes with a large fuel tank to allow for long operating hours in the field. The tank typically holds about 80 gallons (303 liters) of diesel fuel.
This means you can work for extended periods without frequent refueling stops. Always use high-quality diesel fuel with low sulfur content to help maintain engine health and reduce emissions.
You should check the fuel level before each use. Keeping the tank full can prevent moisture from entering and reducing condensation inside the tank.
The fuel tank is designed to be easy to access for quick refueling.
DEF-Tank Capacity (If Applicable)
The AGCO RT120 tractor is equipped with an engine that meets Tier II emission standards. Diesel exhaust fluid (DEF) systems are usually required only on models that meet more advanced emission regulations, such as Tier IV Final.
For the RT120, a DEF tank is not present, and there is no requirement to use DEF when operating this tractor. You do not need to refill a DEF tank or worry about DEF system maintenance on this model.
Focus instead on proper fueling practices and regular maintenance of the diesel fuel system.
Engine Oil Capacity
For optimal performance and engine longevity, it is important to use the correct type and amount of engine oil. The Cummins 6.7L 6-cylinder engine in the RT120 holds about 17 quarts (16 liters) of engine oil.
You should use oil that meets or exceeds manufacturer standards, usually a 15W-40 API CJ-4 or similar diesel engine oil. Check the oil level using the dipstick before each use.
Change the oil and oil filter according to the intervals specified in your owner’s manual, usually every 250 hours of operation. Keeping the oil clean and fresh is essential to protect engine components and maintain performance.
Hydraulic/Transmission Oil Capacity
The hydraulic and transmission systems on the AGCO RT120 share the same fluid reservoir. The combined system holds approximately 22 gallons (83 liters) of hydraulic/transmission oil.
Using the correct tractor transmission/hydraulic fluid is vital for smooth operation and to protect internal parts from wear. Check the fluid level with the designated sight glass or dipstick.
Replace the fluid at the intervals recommended by the manufacturer, and always use oil that matches AGCO’s specifications. Regular filter changes and fluid checks help prevent overheating and hydraulic system failures.
| Fluid Type | Specification | Capacity | Maintenance Tips | Special Notes |
|---|---|---|---|---|
| Diesel Fuel | Ultra-low sulfur diesel | 80 gal (303 L) | Check daily, keep full to reduce condensation | Easy access for refueling |
| Diesel Exhaust Fluid (DEF) | Not required (Tier II emissions) | N/A | No DEF system on this model | None needed |
| Engine Oil | 15W-40 API CJ-4 (or similar) | 17 qt (16 L) | Check before use, change filter & oil per schedule | Protects engine longevity |
| Hydraulic/Transmission Fluid | AGCO-specific transmission/hydraulic fluid | 22 gal (83 L) | Check regularly, replace as recommended | Shared reservoir |
Electrical System
The AGCO RT120 tractor uses a modern electrical system designed for reliability and efficient performance. The system includes a robust charging setup, dependable starting power, and clear specifications tailored for heavy farm work.
Ground Type (Negative / Positive)
The electrical system of the AGCO RT120 operates using a negative ground setup. In negative ground systems, the negative battery terminal is connected to the tractor chassis.
This is the most common configuration in modern tractors and farm equipment. A negative ground helps reduce the risk of corrosion on electrical contacts and makes servicing electrical issues easier.
It also allows you to use standard 12V accessories and diagnostic tools. With a negative ground, you must ensure all accessory wiring and equipment match this convention to avoid electrical shorts or component damage.
Most replacement parts designed for the RT120 are already configured for negative ground use.
Alternator / Charging System
The RT120 is equipped with a 12-volt alternator as its main charging system. The alternator is responsible for providing electrical current to power the tractor’s lights, controls, and other electrical accessories while maintaining battery charge.
You can expect a robust, high-quality alternator that is built for the constant demands of agricultural work. The alternator is typically an Iskra/Letrika/MAHLE unit, which offers strong durability and consistent power delivery.
This alternator uses a 1-wire setup and features both threaded I and R terminals, making maintenance straightforward. Proper alternator function is critical to avoid battery drain, especially during long periods of operation with heavy electrical loads such as air conditioning, lighting, or powered implements.
Charging Output (Amps)
The charging system on the AGCO RT120 delivers a strong output of 120 amps. This high output capacity is essential for meeting the needs of modern farming equipment, which often includes multiple work lights, sensors, and electronic controls.
A 120-amp alternator provides enough current to keep the battery fully charged even under heavy load. It gives you the ability to run various electrical accessories without experiencing a drop in battery voltage.
When checking or replacing your alternator, make sure it matches this output rating. Lower-rated alternators may not support all of the RT120’s electrical requirements, leading to charging problems or frequent battery failures.
Battery Voltage
The AGCO RT120 uses a standard 12-volt battery system. This is the industry standard for tractors in its class and allows compatibility with a wide range of starter motors, lights, and electronic components.
A 12V battery provides reliable starting power, even in cold weather. It is important to keep battery terminals clean and secure to ensure you get the full performance from your electrical system.
Routine battery checks help avoid starting problems, dim lighting, or erratic electrical behavior. When replacing the battery, always verify it is a 12V unit that meets the OEM requirements.
Battery CCA Rating
The Cold Cranking Amps (CCA) rating of your battery is important for starting the engine in all conditions. For the AGCO RT120, the battery should have a CCA rating appropriate for a 150 hp diesel engine.
You typically need a battery with at least 950–1000 CCA. Using a battery with lower CCA can result in slow engine cranking or even prevent the tractor from starting.
Always check the manufacturer’s specification for the minimum CCA requirement. When replacing your battery, select one that matches or exceeds this figure.
| Feature | Specification | Details |
|---|---|---|
| Ground Type | Negative Ground | Negative terminal connected to chassis; standard in modern tractors |
| Alternator | 12V, Iskra/Letrika/MAHLE | 1-wire system; 120 amp rated output |
| Charging Output | 120 Amps | Supports lights, controls, and heavy accessories |
| Battery Voltage | 12 Volts | Standard for tractor class; supports OEM electrical equipment |
| Battery CCA | 950–1000 CCA (recommended) | Ensures reliable starting for 150 hp diesel engine |
Total Cost Of Ownership Metrics
When you buy an AGCO RT120 tractor, you need to think about long-term ownership costs. These costs include routine service intervals, regular maintenance expenses, depreciation rates, and fuel used during operation.
Recommended Service Intervals
AGCO recommends that oil and filter changes occur every 250 operating hours for the RT120. Hydraulic fluid and filter replacements are typically due at 500-hour intervals.
Air filters should be inspected at least every 100 hours, with cleaning or replacement as needed. Drive belt inspections are important every 250 hours.
Cooling system checks are advised at 500 hours to prevent overheating. Following the manufacturer’s maintenance schedule can help extend the lifespan of your tractor.
Below is a recommended maintenance schedule:
| Component | Service Interval | Task |
|---|---|---|
| Engine Oil/Filter | Every 250 hours | Change |
| Hydraulic System | Every 500 hours | Replace fluid and filter |
| Air Filter | Every 100 hours | Inspect; clean or replace if needed |
| Drive Belts | Every 250 hours | Inspect |
| Coolant System | Every 500 hours | Inspect and flush as needed |
Estimated Annual Maintenance Cost
The yearly maintenance cost for an AGCO RT120 depends on usage and local labor rates. Owners who use their tractors extensively can expect higher costs due to more frequent servicing and replacement parts.
On average, you can expect to pay $2,000 to $3,000 per year for routine maintenance such as fluids, filters, belts, and labor. This does not include major repairs.
If the tractor operates in tough conditions, such as heavy tillage or on rough ground, costs can be higher.
Here’s a breakdown of common annual maintenance expenses:
| Maintenance Item | Estimated Cost per Year |
|---|---|
| Engine Oil/Filters | $400 |
| Hydraulic System | $500 |
| Air Filter | $150 |
| Labor | $800 |
| Misc Parts & Fluids | $300 |
Depreciation Curve (% Per Year)
The AGCO RT120 tends to lose value over time, and it is important to factor in depreciation. Most new tractors depreciate fastest in the first few years and then level out.
For the RT120, a typical depreciation pattern is:
- 20% loss in year 1
- 10% per year for years 2 through 5
- After year 5, annual depreciation slows to about 5% per year
Here is a sample depreciation table for a $100,000 purchase price:
| Year | Value Remaining (%) | Value ($) |
|---|---|---|
| 1 | 80 | $80,000 |
| 2 | 70 | $70,000 |
| 3 | 60 | $60,000 |
| 4 | 50 | $50,000 |
| 5 | 40 | $40,000 |
| 6+ | ~35 and below | $35,000 or less |
Fuel Consumption @ Rated Load (L Hr⁻¹)
When running at rated load, the AGCO RT120’s fuel use becomes a key part of your operating costs.
The RT120 is equipped with a six-cylinder diesel engine that uses about 25 to 28 liters of fuel per hour at full power, according to typical real-world reports.
Fuel use will be lower at partial load or during lighter tasks.
If you often do heavy work like plowing or hauling, expect fuel expenses to make up a significant part of your operating budget.
A summary of typical hourly fuel use:
| Load Level | Fuel Use (L/hr) |
|---|---|
| Idle/Light Load | 8–12 |
| Moderate Load | 15–20 |
| Rated Load | 25–28 |
